Specifications
| Adjustable Parallax | Side Focus |
|---|---|
| BDC Dial Included | No |
| Custom Dial System (CDS) | No |
| Daylight Bright Illumination | No |
| Elevation Adjustment Type | M5C3 |
| Electronic Reticle Level | No |
| Guard-Ion Lens Coating | No |
| Illuminated Reticle | No |
| Locking Dial | Yes |
| Magnification Type | Variable |
| Motion Sensor Technology (MST) | No |
| Nightvision Compatible Illumination | No |
| Revolution Indicator | Yes |
| Reticle | FFP PR2-MIL |
| Rezero Type | Set Screw |
| Reticle Type | First Focal Plane |
| Adjustable Objective | No |
| Precision Side Focus | No |
| Windage Adjustment Type | Zero-Lock WIndage |
| Weight (oz) | 30 |
| Elevation Adjustment Value per Click | 0.1Mil |
| Elevation Adjustment Range (MOA) | 70 |
| Elevation Adjustment Range (MIL) | 20 |
| Elevation Adjustment Range (cm @ 100m) | 200 |
| Elevation Adjustment Per Revolution | 10 MIL |
| Elevation Dial Travel Limit | Total Scope Travel |
| Windage Adjustment Value per Click | 0.1Mil |
| Windage Adjustment Range (MOA) | 45 |
| Windage Adjustment Range (MIL) | 13 |
| Windage Adjustment Range (cm @ 100m) | 130 |
| Windage Adjustment Per Revolution | 10 MIL |
| Magnification Max | 32 |
| Magnification Min | 8 |
| Objective Lens Diameter (mm) | 56 |
| Linear FOV Low Mag (ft@100yds) | 13.1 |
| Linear FOV High Mag (ft@100yds) | 3.4 |
| Angular FOV Low Mag (Degrees) | 2.5 |
| Angular FOV High Mag (Degrees) | .7 |
| Eye Relief Low Mag (in) | 4.2 |
| Eye Relief High Mag (in) | 3.9 |
| Minimum Parallax-Free Distance (yd) | 25 |
